The world's first universal magnetic linkage tracking inductionless vector control is the core technology of intelligent drive of permanent magnet DC brushless motor. It has independent intellectual property rights, high efficiency, high function factor, and can directly drive the permanent magnet motor products of different manufacturers, truly realizing intelligent drive.

2.7 HP Technical Parameters

Output power 2000 [W]

Overall efficiency (including motor):

η ≧87【%】（220Vac）

η ≧84【%】（115Vac）

Power factor: cos φ ﹥99[%]

Size: L320 * W250 * H300 (mm)

Speed regulation mode: built-in RS485 communication interface,

It can be controlled by the upper computer (customized according to customer requirements)

Waterproof grade: IPX5

Vibration: 20G

Input voltage: 103~270 [Vac]

Rated current: In ＜ 10.5 [A] (220Vac) In ＜ 15 [A] (115Vac)

Operating temperature: - 20 ℃~+45 ℃

Relative humidity: 20~95 [% RH]

Multiple protections such as overcurrent, overvoltage and short circuit have passed 6KV surge test

Pass CE/CB/ETL certification test
